High speed automatic 18kg stretch film rewinder is a specialized quipment for
rewinding stretch film. It can automatically rewind master rolls of film into standard
finished rolls weighing 12kg,13kg,15kg,18kg and 20kg to meet various packaging
needs.
Machine built by PLC programmer device+LCD touch screen for user firendly.Speed
is flexible controlld by inverter.
It is suited for both machine roll and hand roll rewinding for pallet stretch wrap,hand
stretch wrap.food stretch wrap etc.
Features:
1.Automatic film feeding, cutting, and roll changing functions reduce manual
intervention and improve production efficiency.
2.Compatible with various paper core sizes, 1.5inch, 2inch and 3inch etc.
Main Data:
Name:High Speed Automatic 18Kg Stretch Film Rewinder
Model: PPD-18KG
Jumbo roll width:max500mm
Jumbo roll ID:76mm (3inch)
Jumbo roll OD:max500mm
Rewind roll width:max500mm
Rewind roll ID:38/50/76mm (1.5/2/3inch)
Rewind roll OD:max230mm
Speed:max1200m/min
Power:4.37kw
Voltage:220/380/415V,50Hz
